  • Reet
    Senior Member
    • Dec 2007
    • 552

    #46
    Biggest problem with Omnimic is the noise floor is quite poor, with just a basic USB audio codec. OM1 mic has low self noise, and can be connected to low noise ADC. Here's some basic comparison I made some years back when I got it, and used Steinberg UR22mkii at the time, I am using Motu M4 now which is even better.

    Before I packed my Omnimic away again, I thought I'd take a quick comparison of distortion result between the Omnimic and my current setup consisting of a Line Audio OM1 and a Steinberg UR22mkii USB interface.


    I haven't bothered to do any more comparison than that. The OM1 mic has proven to be perfectly adequate. Omnimic only collects dust now, until I decide I need absolute SPL reading.
    https://discord.gg/h5SuNKDJfx

    Comment

    • Reet
      Senior Member
      • Dec 2007
      • 552

      #47
      Coming soon, Satori MW16P. Probably nothing new to be learned from my testing, since it's already well tested by Hificompass. That will be it for my driver testing for some time.

      Next up will be some waveguide experimentation with a few of the tweeters tested here. I will be milling waveguides in wood with a CNC machine, it may take a bit for me to dial in the settings, but should be able to provide some direct comparison to the stock flat faceplates, in the same cabinet and baffle location.
      https://discord.gg/h5SuNKDJfx

      Comment

      • theSven
        Master of None
        • Jan 2014
        • 1428

        #48
        Originally posted by Reet
        Coming soon, Satori MW16P. Probably nothing new to be learned from my testing, since it's already well tested by Hificompass. That will be it for my driver testing for some time.

        Next up will be some waveguide experimentation with a few of the tweeters tested here. I will be milling waveguides in wood with a CNC machine, it may take a bit for me to dial in the settings, but should be able to provide some direct comparison to the stock flat faceplates, in the same cabinet and baffle location.
        Looking forward to see some more waveguide testing. The CNC sounds like a fun time and different from the 3d printing that has been shared lately on the forum.
        Painter in training

        Comment

        • Reet
          Senior Member
          • Dec 2007
          • 552

          #49
          I have ideas to mill some nice shapes directly into a baffle, it can look pretty cool when done well. Image courtesy of Joseph Crowe.
          Click image for larger version  Name:	image.png Views:	0 Size:	184.4 KB ID:	951325

          I did a quick test run as a proof of concept a while back, just to show that I can do it. I made a model in FreeCAD in a way that I can very easily modify the throat, mouth, and curve profile to dial it in just right.

          Click image for larger version  Name:	image.png Views:	0 Size:	590.6 KB ID:	951326

          For those without CNC or 3D printers, DIY waveguides are not out of reach, there is always the plaster method:
          Something i would like to share with the rest of the (DIYaudio) world, is a way of making (round) waveguides. First model was a 250Hz tractrix midhorn. And more recently an oblate spherical like 10inch hf waveguide. The material i use is plaster. It takes about 2 weeks to dry, depending on...


          https://discord.gg/h5SuNKDJfx

          Comment

          • technodanvan
            Super Senior Member
            • Nov 2009
            • 1052

            #50
            Does one try to smooth that out via sanding or fill it with Bondo (or similar) to get a smooth finish?
            - Danny

            Comment

            • Reet
              Senior Member
              • Dec 2007
              • 552

              #51
              5 min of sanding and it's smooth. That is just a "quick test run proof of concept" as I said, router bit with 40% step over. For final cut I would do more like 10% step over, it'll take a lot longer to machine, but require very little cleanup when complete.
              https://discord.gg/h5SuNKDJfx

              Comment

              • technodanvan
                Super Senior Member
                • Nov 2009
                • 1052

                #52
                Interesting stuff, worth looking into in the future.
                - Danny

                Comment

                • Steve Manning
                  Moderator
                  • Dec 2006
                  • 1900

                  #53
                  Originally posted by technodanvan
                  Does one try to smooth that out via sanding or fill it with Bondo (or similar) to get a smooth finish?
                  Here you go Danny in terms of needing sanding ....

                  This is a waveguide test I did for Jon some time ago. It's a two sided machine .... backside for mounting hardware and then flip for the actual waveguide.


                  Click image for larger version

Name:	DSC_3784_2.jpg
Views:	340
Size:	277.1 KB
ID:	951338

                  Click image for larger version

Name:	DSC_3789_2.jpg
Views:	331
Size:	286.7 KB
ID:	951339

                  This is the roughing pass to remove the bulk of the material.

                  Click image for larger version

Name:	DSC_3791_2.jpg
Views:	336
Size:	258.9 KB
ID:	951340

                  This is the finish pass, no sanding at this point.

                  Click image for larger version

Name:	DSC_3796_2.jpg
Views:	339
Size:	247.9 KB
ID:	951341

                  Part cut out, still no sanding.

                  Click image for larger version

Name:	DSC_3802_2.jpg
Views:	330
Size:	316.5 KB
ID:	951342



                  Hold on to your butts - It's about to get Musical!



                  WEBSITE: http://www.smjaudio.com/

                  Comment

                  • Reet
                    Senior Member
                    • Dec 2007
                    • 552

                    #54
                    SB Satori MW16P-8.
                    Click image for larger version  Name:	image.png Views:	0 Size:	1.14 MB ID:	951431

                    Apart from a blip at 1.5kHz that is likely from the surround, the frequency response is very good. There is no damping goo on front or back side of this driver at the cone-surround edge, which I think could alleviate this problem. Unfortunate miss on this calibre of driver.
                    Click image for larger version  Name:	image.png Views:	0 Size:	135.1 KB ID:	951432

                    IB estimation.
                    Click image for larger version  Name:	image.png Views:	0 Size:	25.8 KB ID:	951433

                    Distortion tested at 2.8V. Again, other than 1.5kHz blip, it's top tier.
                    ​​Click image for larger version

Name:	image.png
Views:	292
Size:	129.3 KB
ID:	951439

                    Again at +5dB (~5V).
                    Click image for larger version

Name:	image.png
Views:	297
Size:	137.2 KB
ID:	951440
                    Last edited by Reet; 03 March 2024, 12:20 Sunday.
                    https://discord.gg/h5SuNKDJfx

                    Comment

                    • tktran
                      Senior Member
                      • Jan 2005
                      • 663

                      #55
                      That higher order distortion really is outstanding!
                      That motor is fantastic; and I like the low weight of the driver too.

                      I wish SB would put an alu cone on the Satori motor. But I wonder if that would cannibalize sales from the Textreme Satori.

                      Comment

                      • duvixan
                        Member
                        • Sep 2012
                        • 63

                        #56
                        Originally posted by tktran
                        I wish SB would put an alu cone on the Satori motor.
                        Marten's Parker series uses OEM ceramic 7.5" Satoris with a grill, to make them look Accuton-y

                        Click image for larger version

Name:	49U5847.jpg
Views:	276
Size:	165.9 KB
ID:	951509


                        Comment

                        • Reet
                          Senior Member
                          • Dec 2007
                          • 552

                          #57
                          A couple more are coming soon. Vifa/Tymphany/Peerless NE180W-08 will be added, as well as Peerless/Tymphany HDS Exclusive 830883.
                          https://discord.gg/h5SuNKDJfx

                          Comment

                          • Reet
                            Senior Member
                            • Dec 2007
                            • 552

                            #58
                            Vifa/Peerless/Tymphany NE180W-08. Great looking and performing midwoofer. Similar type of cone to Satori, I like the look of the yellow reeds in the NE180 better. Motor looks somewhat unimpressive as a small lightweight thimble, but performance is high, and light weight is important for some applications. Potentially, the rear wave may be fairly unobstructed for a dipole.
                            Click image for larger version

Name:	image.png
Views:	211
Size:	1.54 MB
ID:	951648

                            Frequency response is very smooth, with mild breakup.
                            Click image for larger version

Name:	image.png
Views:	207
Size:	170.5 KB
ID:	951649

                            IB Estimation.
                            Click image for larger version

Name:	image.png
Views:	206
Size:	31.1 KB
ID:	951650

                            Distortion at 2.8V.
                            Click image for larger version

Name:	image.png
Views:	205
Size:	168.1 KB
ID:	951651

                            Again at +5dB (~5V).
                            Click image for larger version

Name:	image.png
Views:	210
Size:	173.8 KB
ID:	951652

                            With a filter applied with 2.5kHz LR4 target.
                            Click image for larger version

Name:	image.png
Views:	203
Size:	165.0 KB
ID:	951653

                            https://discord.gg/h5SuNKDJfx

                            Comment

                            • Reet
                              Senior Member
                              • Dec 2007
                              • 552

                              #59
                              Peerless 830883 HDS Exclusive. These are Tymphany branded, not the old DST drivers. Also a very nice driver, maybe a bit better performer than NE180W.
                              Click image for larger version

Name:	image.png
Views:	201
Size:	1.40 MB
ID:	951662
                              Frequency response.
                              Click image for larger version  Name:	image.png Views:	0 Size:	166.1 KB ID:	951655

                              IB estimation.
                              Click image for larger version  Name:	image.png Views:	0 Size:	34.1 KB ID:	951656

                              Distortion at 2.8V.
                              Click image for larger version  Name:	image.png Views:	0 Size:	164.2 KB ID:	951657

                              Again at +5dB (~5V).
                              Click image for larger version  Name:	image.png Views:	0 Size:	167.8 KB ID:	951658

                              With a filter applied for 2.5kHz LR4 target.
                              Click image for larger version  Name:	image.png Views:	0 Size:	162.4 KB ID:	951659
                              https://discord.gg/h5SuNKDJfx

                              Comment

                              • Reet
                                Senior Member
                                • Dec 2007
                                • 552

                                #60
                                Directivity comparison. Here is power & di chart of normalized response for NE180W and 830883, very similarly sized drivers, but with different cone profiles, and of course one has a "phase plug". Dashed lines is NE180W, solid 830883.

                                Click image for larger version

Name:	image.png
Views:	209
Size:	98.9 KB
ID:	951661
                                https://discord.gg/h5SuNKDJfx

                                Comment

                                • tktran
                                  Senior Member
                                  • Jan 2005
                                  • 663

                                  #61
                                  Thanks Reet

                                  My analysis is that the Satori has the best motor. The higher order distortion products are about ~6-10dB better than the rest. No wonder a certain doctor from KEF thought I was referring to the Satori when I was giving feedback about his coaxial.
                                  The 2nd order is a bit higher than the rest, probably due to the cone. 5th element has been championing for a metal cone Satori for a long time, and I concur.

                                  The 830883 is a little better than the NE180W. Below 250Hz it's better, and it has a slightly smoother response.
                                  How does the silver frame look like in person?
                                  There's still plenty of stock down under (since we're the last to get things, we seem to be the last to run out of things)

                                  Perhaps it will go well with modern finishes like white cabinets...

                                  Comment

                                  • Reet
                                    Senior Member
                                    • Dec 2007
                                    • 552

                                    #62
                                    If the Peerless HDS is goes with your modern decor, then it must have been ahead of it's time

                                    I like it's unique character, you definitely won't mistake it for anything else. Finish is not silver, but rather light grey, almost an industrial powder coat in appearance.

                                    Click image for larger version  Name:	image.png Views:	0 Size:	740.1 KB ID:	951695
                                    https://discord.gg/h5SuNKDJfx

                                    Comment

                                    • duvixan
                                      Member
                                      • Sep 2012
                                      • 63

                                      #63
                                      Both still available on aliexpress


                                      Comment

                                      • Reet
                                        Senior Member
                                        • Dec 2007
                                        • 552

                                        #64
                                        Scan-Speak D2604/832002 "Limited Edition" tweeter. These are NLA, but as far as I can tell, the only difference from the standard D2604 is that they have a nice cast aluminum faceplate instead of plastic, and the voice coil former is titanium.
                                        Click image for larger version

Name:	image.png
Views:	323
Size:	1.26 MB
ID:	953444

                                        Frequency response:
                                        Click image for larger version

Name:	image.png
Views:	294
Size:	126.6 KB
ID:	953445

                                        IB Estimation.
                                        Click image for larger version

Name:	image.png
Views:	287
Size:	27.7 KB
ID:	953446

                                        Distortion tested at 2.8V, quite impressive.
                                        Click image for larger version

Name:	image.png
Views:	289
Size:	129.6 KB
ID:	953447

                                        Again at +5dB.
                                        Click image for larger version

Name:	image.png
Views:	294
Size:	130.6 KB
ID:	953448
                                        https://discord.gg/h5SuNKDJfx

                                        Comment
